LIQUID ANALYSIS

LTH RPL Series Radar Level Transmitters are suitable for continuous non contact level measurement applications for solids, liquid, pulps and slurries.

LTH SWING Controller for IP65 surface mounting has been designed as a general purpose controller for use with either 1 or 2 Ultrasonic level sensors from either the PTU or Smart series.

LTH MCL Liquid Level Controller has been designed to provide efficient and reliable level control of electrically conducting liquids. The MLC is available in DIN rail mounting format or can be supplied in an IP65 plastic enclosure which can either house one or two controllers to suit the system requirements.

LTH S and T Series Suspended Solids Instruments combined with a series of Quadbeam™ sensors provide accurate and reliable measurement of Suspended solids and Turbidity.

The HPT63 is a microprocessor based pH or Redox transmitter. Two different options of the HPT63 transmitter are available with the Base model offering a single industry standard 4-20mA output. The Advanced HPT63 will offer two 4-20mA outputs enabling the process temperature to be measured and transmitted as well as either the pH or Redox value. The Advanced HPT63 model will have 2 relay outputs for process control and also 3 digital inputs for on-line/off line and clean function selection via a plc.

Aimed primarily at simple pH and Redox control applications the instruments retain only the most important functions. This has two benefits; it reduces the purchase price and simplifies the installation and operation of the instrument, without compromising quality or reliability.

The S400 sensors have been designed for rugged service in submersion or inline process applications. The reference cell features a double junction design for extended service life in harsh applications. The high quality sensors are constructed of corrosion resistant wetted materials including Ryton®, Teflon®and glass. They can be supplied with built in temperature compensation and a solution ground connection.

The 9000 series pH & Redox sensors are designed for direct installation into a pipe or in the wall of a tank for continuous pH or Redox monitoring and control. These sensors have a large non-clogging peripheral reference junction, which is constructed in annular form around the sensing electrode. The 9000 series sensors have a Kynar body with a 0.5” NPT male threaded process connection and must always be installed at least 15 ° above horizontal for correct operation.

The P11, P14, O11, O14 AND GT135 electrodes are 12mm diameter electrodes with the European standard PG13.5 configuration. The 12mm x 120mm size fits a wide array of housings found in both industrial and waste water treatment applications. This standard design simplifies electrode stocking, as one sensor can now serve as a replacement for numerous installations.

DynaProbes were designed to withstand the aggressive environment of pulp and paper manufacturing. The patented internal design features a solid state, reference half-cell with the unique IonTrap™ for extended sensor life in the most severe applications. Choose from the different body styles, body materials, reference materials and bulb designs to create a sensor to fit any industrial application. The three primary sensor designs are: Twist Lock, Pipe Thread, and Valve Retraction.
